121
SPECIFICATIONS
Jetting Chart
Clutching Chart
Sportsman 500
Driving System Type Automatic PVT (Polaris Variable Transmission)
Front Suspension MacPherson strut with 8.2" (21 cm) travel
Rear Suspension Progressive rate with 9.5" (24 cm) travel
Shift Type Side Lever (H/L/N/R/P)
Gear Reduction, Low 23.91:1
Gear Reduction, Reverse 16.30:1
Gear Reduction, Forward 10.49:1
Drive Ratio, Front 3.82:1
Tires/Pressure, Front 25x8-12 / 5 psi
Tires/Pressure, Rear 25x11-12 / 5 psi
Brakes, Front Single-Control Hydraulic Disc
Brakes, Rear Single-Control Hydraulic Disc
Brake, Auxiliary Foot-Activated Hydraulic Disc
Brake, Parking Hydraulic lock, all wheel
Headlight 1 Single Beam on Headlight Pod (50 watt)
2 Single Beam on Bumper (37.5 watt)
Taillights 8.26 watts
Brake Light 26.9 watts
Instrument Cluster LCD
ALTITUDE
Meters (Feet)
AMBIENT TEMPERATURE
Below 40° F
(Below 5° C)
+40°F and above
(+5°C and above)
0-1800 (0-6000) 160 155
1800-3700
(6000-12000)
152.5 147.5
Altitude Shift
Weight
Drive Clutch
Spring
Driven
Clutch
Spring
Helix and
Spring
Setting
Meters
(Feet)
0-1800
(0-6000)
10 WH
PN 5630710
Blue/Green
PN 7041157
Black
PN 7041782
41-37°
PN 5132344
2+2
1800-3700
(6000-12000)
10 RH
PN 5630709
Blue/Green
PN 7041157
Black
PN 7041782
41-37°
PN 5132344
2+2
