16
DC Power
The 36–60 VDC DC to DC adapter supplied with the DC version of the
Model 2701 plugs in a DC source (nominal 48 VDC) and plugs into the
barrel power supply jack on the rear of the 2701. Refer to Figure 5 to
make the proper connection.
Figure 5. Connecting DC Power to the 2701 DC Power Supply.
WARNING
There are no user-serviceable parts in the
power supply section of the Model 2701. Con-
tact Patton Electronics Technical support at
(301)975-1007, via our web site at http://
www.patton.com, or by e-mail at support@pat-
ton.com, for more information.
