Switch SW1-1 through SW1-5
A detailed description of each switch (SW1-1 through SW1-5) setting fol-
lows the summary table below.
Table 1:
Switch Set 1 Summary Table
SW1
SW2
SW3
SW4
SW5
Speed
On
On
On
On
On
64 kbps
Off
On
On
On
On
128 kbps
On
Off
On
On
On
192 kbps
Off
Off
On
On
On
256 kbps
On
On
Off
On
On
320 kbps
Off
On
Off
On
On
384 kbps
On
Off
Off
On
On
448 kbps
Off
Off
Off
On
On
512 kbps
On
On
On
Off
On
576 kbps
Off
On
On
Off
On
640 kbps
On
Off
On
Off
On
704 kbps
Off
Off
On
Off
On
768 kbps
On
On
Off
Off
On
832 kbps
Off
On
Off
Off
On
896 kbps
On
Off
Off
Off
On
960 kbps
Off
Off
Off
Off On
1024
kbps
On
On
On
On
Off
1088 kbps
Off
On
On
On
Off
1152 kbps
On
Off
On
On
Off
1216 kbps
Off
Off
On
On
Off
1280 kbps
