Setup

Ink film – installing / replacing

Open the front cover by pulling up the centre
part.

Centre part

Front cover

Push the back cover open button (green) on
the right side of the unit.
OR
Push the back cover open lever (green)
inside of the unit.

Back cover
open button
(green)

Back cover
open lever (green)

Open the back cover.

●

For first time installation of the supplied ink
film, skip to step 6.

Back cover

Install the included ink film or replace the used ink film with new one.
Model No. KX-FA55X: Replacement film (2 rolls)
Each roll prints about 140 A4-sized pages. See page 7 for accessory information.

For replacement only
Pull out the blue gear and remove the used
ink film. Remove the used core.

Used core

Used
ink film

Blue
gear

(continued)
