Programming the SWI-JACK to Control the Head Unit (cont.)
The SWI-JACK must be programmed in the specific order shown in the chart below. If a function is not needed, it may be skipped by
pressing the Program/Mode button 1 time per function in its place. The LED will flash once (indicating the function has been skipped)
and then illuminate, waiting for the next button to be pressed. Adjust the Radio Select switch on the side of the SWI-JACK according to
the chart. Alpine = 1, JVC = 2, Kenwood = 3, Clarion = 4 and Blaupunkt = 5.
Alpine JVC Kenwood Clarion Blaupunkt
Radio Select Switch
Setting 1 2 3 4 5
1. Vol up Vol up Vol up Vol up Vol up
2. Vol down Vol down Vol down Vol down Vol down
3. Mute Mute/Power Mute Mute mute
4. Preset up Preset up Source Track up Source
5. Preset down Source Seek up Track down Track up
6. Source Seek up Track up Band Track down
7. Track up Seek down Track down Source Disc up
8. Track down Select Disc Up/FM Disc down
9. Power Band Disc Down/AM OK
10. Ent/Play
11. Band/program
1
2 3 4 5
6 7
8 9
0
Radio Select Switch located on
the side of SWI-JACK interface
