Planar PR Line PR5022 - Manual (Page 10)

DLP
®
Projector – User’s Manual
Views of Projector Parts
Front-right View
Item Label Description See page:
1. Focus Focuses the projected image 18
2. Lens zoom Enlarges the projected image 18
3. Screws Holds lamp to projector
4. See “Top view—OSD buttons and LEDs” 3
5. Front IR receiver Receiver for IR signal from remote control 7
6. Lens Slide lens cap before use.
7. Lens cover Slide across to protect lens when not in use
