Option Menu

-23-

Menu Operation

PIP means picture in picture, the unit can display a sub window on the screen, which
displays the program from another video source.
This feature is valid when Main Window is in PC mode. You can watch TV or other
video on the sub window.

PIP

Please make sure TV set is in PC mode first.
Press "PIP" button to display the "Sub Source" Menu:

Press the direction buttons to select the source of sub window.
Press "ENTER" button to enter the menu.

* The input signal of Main Window should be:

1. 1024 x 768 60Hz, PC signal
2. 800 x 600 60Hz, PC signal
3. 640*480 60Hz, PC signal
4. 480P, DVD player VGA signal 60Hz
5. 576P, DVD player VGA signal 50Hz

PIP Function

Sub Source

MAIN WINDOW

SUB WINDOW
