ANSI Std. Rated Approx. Approx.
Product Ordering Nom. Code/ Pkg. LCL MOL Avg. Life Initial Mean CCT
Number Code Watts Bulb Base Ballast Ref. Qty. Description (In.) (In.) Hrs. 1 Lumens 2 Lumens 3 CRI (K)
30632-4 C35S76/M 35 BD-17 Med. S76 12 G (4, 6, 9, 12) 3 7 ⁄
16
5 7 ⁄
16
24,000+ 2250 2025 21 2100
30633-2 C35S76/D/M 35 BD-17 Med. S76 12 G (4, 6, 9, 12) — 5 7 ⁄
16
24,000+ 2150 1935 21 2100
30336-2 C50S68/M 50 BD-17 Med. S68 12 G (4, 6, 9, 12) 3 7 ⁄
16
5 7 ⁄
16
24,000+ 4000 3600 21 2100
30337-0 C50S68/D/M 50 BD-17 Med. S68 12 G (4, 6, 9, 12) — 5 7 ⁄
16
24,000+ 3800 3420 21 2100
36867-0 C50S68/ALTO 50 ED-23 1 ⁄ 2 Mog. S68 12 G, S (4, 6, 9, 12) 5 7 3 ⁄ 4 24,000+ 4000 3600 21 2100
33154-6 C50S68/D/ALTO 50 ED-23 1 ⁄ 2 Mog. S68 12 G, S (4, 6, 9, 12) — 7 3 ⁄ 4 24,000+ 3800 3420 21 2100
33192-6 C70S62/M 70 BD-17 Med. S62 12 G (4, 6, 9, 12) 3 7 ⁄ 16 5 7 ⁄ 16 24,000+ 6300 5850 21 2100
33214-8 C70S62/D/M 70 BD-17 Med. S62 12 G (4, 6, 9, 12) — 5 7 ⁄
16
24,000+ 5860 5270 21 2100
36869-6 C70S62/ALTO 70 ED-23 1 ⁄
2
Mog. S62 12 G, S (4, 6, 9, 12) 5 7 3 ⁄
4
24,000+ 6500 5670 21 2100
30620-9 C70S62/RFL 70 PAR-38 Med. S62 12 G,VW, 50 (4, 6, 12, 13) — 5 13 ⁄
16
16,000 5000 3960 21 2100
34446-5 C100S54/M 100 BD-17 Med. S54S 12 G (4, 6, 9, 12) 3 1 ⁄
2
5 7 ⁄
16
24,000+ 9500 8550 21 2100
34448-1 C100S54/D/M 100 BD-17 Med. S54S 12 G (4, 6, 9, 12) — 5 7 ⁄
16
24,000+ 8800 7920 21 2100
36872-0 C100S54/ALTO 100 ED-23 1 ⁄
2
Mog. S54 12 G, S (4, 6, 9, 12) 5 7 3 ⁄
4
24,000+ 9400 8460 21 2100
33227-0 C100S54/D/ALTO 100 ED-23 1 ⁄
2
Mog. S54 12 G, S (4, 6, 9, 12) — 7 3 ⁄
4
24,000+ 8610 7750 21 2100
30347-9 C150S55/M 150 BD-17 Med. S55 12 G (4, 6, 9, 12) 3 1 ⁄
2
5 7 ⁄
16
24,000+ 16,000 14,400 21 2100
30348-7 C150S55/D/M 150 BD-17 Med. S55 12 G (4, 6, 9, 12) — 5 7 ⁄ 16 24,000+ 15,000 13,500 21 2100
36874-6 C150S55/ALTO 150 ED-23 1 ⁄ 2 Mog. S55 12 G, S (4, 6, 7, 9, 12) 5 7 3 ⁄ 4 24,000+ 15,800 14,220 21 2100
36876-1 C150S56/ALTO 150 ED-28 Mog. S56 12 G, S (4, 6, 7, 9, 12) 5 8 15 ⁄ 16 24,000+ 15,000 13,950 21 2100
36877-9 C200S66/ALTO 200 ED-18 Mog. S66MN-200 12 G, S (4, 6, 9, 12) 5 3 ⁄
4
9 3 ⁄
4
24,000+ 21,400 19,260 21 2100
32291-7 C225S50/EW 225 ED-18 Mog. S50 12 EW, G, S (4, 6, 9, 12, $) 5 3 ⁄
4
9 3 ⁄
4
24,000+ 27,300 24,620 21 2100
36879-5 C250S50/ALTO 250 ED-18 Mog. S50 12 G, S (4, 6, 9, 12) 5 3 ⁄
4
9 3 ⁄
4
24,000+ 27,000 24,300 21 2100
13469-2 C310S67 310 ED-18 Mog. S67 12 G (4, 6, 9) 5 3 ⁄
4
9 3 ⁄
4
24,000+ 38,000 34,200 21 2100
32292-5 C360S51/EW 360 ED-18 Mog. S51 12 EW, G, S (4, 6, 9, 12, $) 5 3 ⁄
4
9 3 ⁄
4
24,000+ 46,000 41,450 21 2100
36881-1 C400S51/ALTO 400 ED-18 Mog. S51 12 G, S (4, 6, 9, 12) 5 3 ⁄
4
9 3 ⁄
4
24,000+ 50,000 45,000 21 2100
31710-7 SON AGRO/430W 430 ED-18 Mog. S145/S51 12 AGRO (4, 6, 10, 11, 12) 5 3 ⁄
4
9 3 ⁄
4
16,000 54,000 48,600 21 2100
23982-2 C600S106 600 T-14 Mog. S106 12 G (4, 6, 9, 12, 14) 6 7 ⁄ 8 11 1 ⁄ 8 24,000+ 90,000 81,000 21 2100
32386-5 C1000S52/ED37 1000 ED-37 Mog. S52 6 G, S (4 6, 9, 12, 14) 7 11 1 ⁄ 2 24,000+ 125,000 112,000 21 2100
36883-7 C1000S52/ALTO 1000 E-25 Mog. S52XB-1000 6 G, S (4, 5, 6, 8, 9, 12) 8 3 ⁄ 4 15 1 ⁄ 16 24,000+ 131,000 117,900 21 2100
Electrical,Technical and Ordering Data (Subject to change without notice)
ANSI Std. Rated Approx. Approx.
Product Ordering Nom. Code/ Pkg. LCL MOL Avg. Life Initial Mean CCT
Number Code Watts Bulb Base Ballast Ref. Qty. Description (In.) (In.) Hrs. 1 Lumens 2 Lumens 3 CRI (K)
30617-5 C70S62/C/M 70 BD-17 Med. S62 12 G (4, 6, 9, 12) 3 7 ⁄ 16 5 7 ⁄ 16 15,000 4400 3960 60 2200
30635-7 C100S54/C/M 100 BD-17 Med. S54 12 G (4, 6, 9, 12) 3 7 ⁄ 16 5 7 ⁄ 16 15,000 7800 7020 60 2200
30637-3 C100S54/C 100 ED-231⁄2 Mog. S54 12 G (4, 6, 9, 12) 5 7 3 ⁄
4
15,000 7900 7110 60 2200
30647-2 C150S55/C/M 150 BD-17 Med. S55 12 G (4, 6, 9, 12) 3 7 ⁄
16
5 7 ⁄
16
15,000 12,000 10,800 60 2200
30643-1 C150S55/C 150 ED-231⁄2 Mog. S55 12 G (4, 6, 9, 12) 5 7 3 ⁄
4
15,000 12,000 10,800 60 2200
30245-5 C250S50/C 250 ED-18 Mog. S50 12 G (4, 6, 9, 12) 5 3 ⁄
4
9 3 ⁄
4
15,000 23,000 20,700 65 2200
30652-2 C400S51/C 400 ED-18 Mog. S51 12 G (4, 6, 9, 12) 5 3 ⁄
4
9 3 ⁄
4
15,000 37,500 33,750 65 2200
Electrical,Technical and Ordering Data (Subject to change without notice)
Warnings, Cautions and Operating Instructions
WARNING: These lamps must be operated in fixtures
designed for use with High Pressure Sodium lamps.The
fixture wattage rating must match the wattage indicated
on the outer glass bulb. Do not scratch the outer bulb or
subject it to pressure as this could cause the outer bulb to
crack or shatter. A partial vacuum in the outer bulb may
cause glass to fly if the glass is struck. Operating the lamp
improperly may result in PERSONAL INJURY,
PROPERTY DAMAGE, BURNS AND FIRE.
1. If the outer glass bulb is broken, shut off power
immediately and remove the lamp after it has cooled.
2. Use only auxiliary equipment meeting Philips and/or ANSI
standards. Use within voltage limits recommended by ballast
manufacturer.
A. Operate lamp only within specified limits of operation.
B. For total supply load refer to ballast manufacturers
electrical data.
3. Protect lamp base, socket and wiring against moisture,
corrosive atmospheres and excessive heat.
4. Replace the lamp if the outer glass bulb has been scratched,
cracked or damaged in any way.
5. If a lamp bulb support is used, be sure to insulate the support
electrically so as to avoid possible decomposition of the
bulb glass.
6. Do not use this lamp in a fixture which redirects a substantial
portion of the energy toward the arc tube and its immediate
vicinity, as this may lead to very early lamp failure.
7.Take care in handling and disposing of lamps. If arc tube
is broken, avoid skin contact with any of them contents
or fragments.
8.The arc tube of this lamp contains sodium and mercury.
Dispose of in accordance with federal, state and
local requirements.
WARNINGS, CAUTIONS AND OPERATING INSTRUCTIONS for Ceramalux ® High Pressure Sodium Lamps
Ceramalux ® High Pressure Sodium Lamps
◗ Low total cost of ownership
◗ Long life—up to 24,000 hours
◗ High efficacy up to 140 LPW
◗ ALTO ® Lamp Technology passes EPA’s TCLP test for non-hazardous waste
Ceramalux ® Comfort High Pressure Sodium Lamps
◗ Improved color rendition of 65 CRI
◗ High efficacy
◗ Warm white color appearance
◗ Operates on standard HPS ballasts
