Appendix C - Specifications
25
Under normal circumstances, there is no reason to close an HID connection; once
established the connection is maintained automatically, even during the power off and
power on processes.
If, for some reason, the connection must be closed: from My Bluetooth Places, right-
click the service name and select Disconnect.
When an HID connection is closed manually by the operator, the connection
’s
“persistence” is broken. The connection must be re-established manually, after which
the connection will again persist until broken manually.
Configure
No configuration is necessary.
5.5.4 Audio Gateway
Overview
The Audio Gateway Application allows a remote Bluetooth device to use this com-
puter
’s microphone and speakers as the remote device’s audio input and output
devices.
Create a Bluetooth Audio Gateway connection
Open a connection to the Audio Gateway service that is provided by another Bluetooth
device using one of these techniques:
l Windows system tray, Bluetooth icon
l From My Bluetooth Places
l Using the Bluetooth Setup Wizard
Close an audio gateway connection:
If the connection was established via the Bluetooth icon in the Windows system tray;
click the Bluetooth icon, select Quick Connect, Audio Gateway and then select the
device that is providing the service (active connections have a checkmark in front of
them).
or
No matter how the connection was created, in My Bluetooth Places, right-click the
service name and select Disconnect.
Configure
The Bluetooth Configuration Panel > Client Applications > Audio Gateway > General
tab provides options to configure:
l The application name —to change it, highlight the existing name and enter
the new name.
l Enable or disable secure connection. To enable secure connection, place a
checkmark in the box.
5.5.5 Bluetooth Serial Port
Overview
