English | 11
Audio Control
1 Select the source to adjust
Press the [SRC] button.
2 Enter Audio Control mode
Press the [VOL] knob.
3 Select the Basic Audio item to adjust
Press the [VOL] knob.
Each time you press the knob, the item to be
adjusted alternates between the items shown in
the table below.
4 Adjust the Basic Audio item
Turn the [VOL] knob.
Adjustment Item Display Range
Rear Volume * 1 "R-Volume" 0 — 35
Subwoofer level* 2,3 "SW_Level" –15 — +15
Bass level* 4 "Bass Level" –8 — +8
Middle level* 4 "Middle Level" –8 — +8
Treble level* 4 "Treble Level" –8 — +8
Balance "Balance" Left 15 — Right 15
Fader* 3 "Fader" Rear 15 — Front 15
Exit Audio Control mode
• * 1 You can control this item when "2Zone" of
Setup> (page 12) is set to "ON".
• * 2 You can control this item when
(page 33) is set to "SWPRE:Sub-W". (KDC-W707 only)
• * 3 You can control this item when
Output> (page 12) is set to "SW ON".
• * 3 You can control this item when "2Zone" of
Setup> (page 12) is set to "OFF".
• * 4 You can adjust these items in detail by the following
methods. (Function of the KDC-W808)
• * 4 Source tone memory: Puts the set up value in the
memory per source. (Detail Audio item is included)
5 Exit Audio Control mode
Press any button.
Press a button other than the [VOL] knob and
[ATT]/ [ANG] button.
Adjust the detail of Audio Control
1 Select the Audio item to adjust
By referring to the step 1 — 3 above, select the
desired item to be set in detail from the items
marked with *
4 .
2 Enter Detail adjustment mode of Audio
Control
Press the [VOL] knob for at least 1 second.
3 Select the Detail Audio item to adjust
Press the [VOL] knob.
Each time you press the knob, the item to be
adjusted alternates between the items shown
in the table below.
4 Adjust the Detail Audio item
Turn the [VOL] knob.
Bass level
Adjustment Item Display Range
Bass Center Frequency "Bass Freq" 40/50/60/70/80/100/
120/150 Hz
Bass Q Factor "Bass Q" 1.00/1.25/1.50/2.00
Bass Extend "Bass EXT" ON/OFF
Middle level
Adjustment Item Display Range
Middle Center Frequency "Middle Freq" 0.5/1.0/1.5/2.0 kHz
Middle Q Factor
"Middle Q" 1.0/2.0
Treble level
Adjustment Item Display Range
Treble Center Frequency "Treble Freq" 10.0/12.5/15.0/17.5 kHz
5 Exit the Detail Audio Control mode
Press the [VOL] knob for at least 1 second.
• When you set the Bass Extend to ON, low frequency
response is extended by 20%.
• You can exit the Audio Control mode at anytime by
pressing any button except for [VOL], [ANG] and [ATT]
buttons.
