9
Quick Reference Control Operation
L Location of Controls
Front Panel
A POWER
Press
→ On.
Press again → Off.
B VOLUME UP/DOWN
(+) Increases sound.
(–) Decreases sound.
C SENSOR AREA FOR REMOTE CONTROL
D CHANNEL UP/DOWN
(
8 ) Selects next higher channel.
( 9 ) Selects next lower channel.
• Press both at same time to access MAIN MENU Screen.
E VIDEO/AUDIO TERMINALS
(VIDEO/AUDIO terminals are also provided on the rear.) IN 2
A
C
B D
E
• The above shaded buttons on the Remote Control glow in the dark. To use the glow-in-the-dark display on the
remote control, place it under a fluorescent light or other lighting.
• The phosphorescent material contains no radioactive or toxic material, so it is safe to use.
• The degree of illumination will vary depending on the strength of lighting used.
• The degree of illumination will decrease with time and depending on the temperature.
• The time needed to charge the phosphorescent display will vary depending on the surrounding lighting.
• Sunlight and fluorescent lighting are the most effective when charging the display.
NOTE:
07-09 TP3675C 6/9/00, 9:34 AM 9
Basic Remote Control Functions
Infrared Transmitter Window
INPUT STATUS
Press
→ Displays receiving channel for
four seconds.
Press again
→ Removes display.
• Temporarily displays receiving
channel when in Closed Caption
mode.
INPUT
Press once
→ Switch to external video
INPUT 1 mode.
Press again
→ Switch to external video
INPUT 2 mode.
Press again
→
Switch back to the
original TV mode.
See page 34.
ENTER
The “100” button functions as an
“ENTER” button when in the VCR
mode. (See page 36)
CHANNEL UP/DOWN
(
8 ) Selects next higher channel.
( 9 ) Selects next lower channel.
• See pages 27 - 29 for channel
presetting.
• Moves the “ ” mark of the MENU
screens.
MUTE
Press
→ Mutes sound.
Press again → Restores sound.
• CLOSED CAPTION appears when
sound is muted.
SMART WINDOW TM PIP FUNCTION
With the VIDEO inputs, you can watch
two pictures at the same time. See
pages 32 - 33.
1 2 3
4 5 6
7 8 9
0 100
POWER
TV VCR
MENU MUTE
CATV
PAUSE
PIP
TV
A/CH
INPUT
STATUS INPUT
STOP REC
REW PLAY FF
VCR CH
SWAP FREEZE SELECT
CH
CH
A B C D
PERSONAL PREFERENCE
POSITION
G1599SA
POWER
Press
→
On.
Press again → Off.
REMOTE KEYPAD
Accesses any channel from keypad.
A/CH
Returns to previous channel.
PERSONAL PREFERENCE
With the Personal Preference buttons,
you can program your favorite
programs by using the four categories
A, B, C and D. The channels can be
accessed quickly by using these
buttons. (See pages 30 - 31)
VOLUME UP/DOWN
(+) Increases sound.
(–) Decreases sound.
• In menu mode, changes or selects
the TV adjustments.
MENU
Press
→
Accesses MAIN MENU.
Press again → Exits MAIN MENU.
TV-CATV MODE SELECT SWITCH
In TV position, sends power and
channel select commands (Channel
up/down and Random Access buttons)
to the TV.
In CATV position, sends power and
channel select commands to a cable
TV converter.
VCR CONTROL
See page 36.
