Installations and connections
Installing the ink film
2
Insert the ink film.
Insert the white core into the slots shown in the
picture below.
1
Open the control panel.
Find the “T” shaped gear (blue).
Ink film
Insert the blue core into the right slot of the main
unit.
Insert the “T” shaped gear (blue) into the left slot of
the main unit.
“T” shaped
gear (blue)
Blue core
Right slot
White core
Do not be
slacken.
“T” shaped gear (blue)
Click
Control panel
2
Press here.
Open the control
panel until it locks.
If the ink film is slack, tighten it by winding the “T”
shaped gear (blue).
3
Close the control panel until it locks.
