Connections
12
Connect AV Output Terminals
Connect the Audio/Video cables between the Audio (L/R)/Video jacks on the unit and VCR.
To record the desired program, please select a program you wish to record firstly, then turn on your VCR,
insert videotape for recording and press the Record button to begin recording.
Note: The AV output terminals output the audio/video signal from the Antenna input or AV inputs.
VCR for recording
