Chapter 2
2-18
Bluetooth Connector: JBT1 (Optional)
This connector is used to connect a bluetooth module for wireless
connection.
PIN SIGNAL PIN SIGNAL
1 5VDUAL 2 3VDUAL
3 D+ (USB signal) 4 GND
5 D- (USB signal) 6 GND
7 GND 8 NC
Pin Definition
JBT1
7
8
1
2
Note: Because the bluetooth connector shares the USB1.1
connector, the upper USB1 USB 1.1 port will not function
when you attach a bluetooth module to this connector.
