Introduction
1-3
2.88Mbytes.
- 2 serial ports (COM A + COM B).
- 1 parallel port supports SPP/EPP/ECP mode.
- 1 IrDA connector for SIR.
- 1 Line-in/Line-out/Mic-in port.
- 1 RJ45 connector.
USB Interface
4 USB 1.1 ports (Rear * 4, one for BlueTooth Networking function) and 4
NEC USB 2.0 ports (Front * 4) (Optional)
Audio
C-Media CMI8738/PCI-6ch-LX supports 2/4/6 ch speaker
- 6CH DAC for AC3
®
5.1CH purpose.
- HRTF-based 3D positional audio, supporting DirectSound
TM
3D and A3D
TM
interface.
- Supports 4.1/5.1 speakers, C3DX positional audio in 4/6 CH speaker mode.
- Legacy audio SBPRO
TM
compatible.
- DLS-based wavetable music synthesizer.
Intel
®
LAN (Optional)
Intel
®
82562ET chip
- Integrated Fast Ethernet MAC and PHY in one chip.
- Supports 10 Mb/s and 100 Mb/s.
- Compliance with PCI v2.2.
- Supports ACPI Power Management.
BIOS
The mainboard BIOS provides “Plug & Play” BIOS which detects the pe-
ripheral devices and expansion cards of the board automatically.
IDE drive auto configure, Advanced Power Management (APM) 1.2, ACPI
1.0a, DMI 2.0, ECC/Parity support, LS 120 support, PnP 1.0a, SMBIOS 2.3,
WFM 2.0, Auto enables onboard SCSI termintor.
Supports boot from Lan and boot from USB device.
Dimension
ATX Form Factor: 305 mm (L) x 244 mm (W) x 4 layers PCB.
Mounting
12 mounting holes.
