OPERATION
MEMO MEMO
TUNER
TAPE
AV1/AV2
CD
POWER
PHONO SCAN
PRESET EQ
VOLUME
BAND HOLD
EXTERNAL
PROCESSOR
2
1
7
3
4
5
6
R
(1). Power Switch
(2) AM/FM Selector/Memory Scan/Hold
(3) Volume Control Key (+ -)
(4) External Processor
(5) Preset EQ
(6) CD Control Key
* STOP
( )
* CLOSE/OPEN ( )
* PLAY/PAUSE ( )
* SKIP/FAST BACKWARD ( )
* SKIP/FAST FORWARD ( )
(7)Function Keys:
* PHONO
* TUNER
* TAPE
* AV1/AV2
* CD
REMOTE CONTROL
Remote Controlling Instructions
The remote control box can directly control majority
of system functions of HI-FI SYSTEM. The functions
include power control of the whole system, Volume
control, sound field control, CD operation control,
Tuner operation control and also source control
function. This remote controller may not function
properly if an roadblock is located between it and the
receiving unit, or if the remote controller is held at an
improper angle with respect to the receiving unit.
Battery Installation
Remove the rear cover of the remote controller by
sliding it backward. Install two AA (1.5 V) size
batteries, while observing the correct polarity [ match
the (+) and (-)signs].
Sound Field Control Operation
* Switch the power key to connect to electric current.
* Use PRESET EQ key to select the sound mode
decided.
Each time the button is pressed, the mode changes
as follows:
POP → ROCK → CLASSIC → FLAT
TUNER OPERATION BUTTONS
When the function switch is set to Tuner side:
* Press BAND keys for selecting AM/FM channel.
* Memo Scan: Press to scan the stations (0-9) stored
in the station memory.
* Memory Hold: After pressing Memory Scan key,
Tuner will scan through station (0-9). When your
desired station is reached, press MEMORY HOLD
to hold it.
OTHER
* Sound source can be changed directly by pressing
TUNER, PHONO, TAPE, CD or AV1/AV2 key.
* Volume level can be adjusted by pressing VOL
“-“ or “+” keys.
**Note** Exhausted batteries may reduce the level of
sensitivity of the controller.
