Panasonic AJ-P VQT0A45 - Manual (Page 145)

– 145 –
MAIN Menu Screen 4 of 4 (SUB menus)
Sensitivity measurement screen
The settings for the sensitivity measurement are performed on this screen.
Item
SENSITIVITY
KNEE
W.CLIP
M.PED
VIDEO OUT
Variable
range
ON
OFF
ON
OFF
ON
OFF
p 100
.
.
.
o 0
.
.
.
o 100
ENC
Y
R
G
B
Remarks
This selects ON or OFF for the
sensitivity measurement.
This selects ON or OFF for KNEE.
This selects ON or OFF for W.CLIP.
This adjusts the master pedestal.
This switches the VIDEO OUT.
VF
display
ENG
ENG
ENG
ENG
ENG
The underlining in the variable range column indicates the setting in the preset mode.
USER menu: The USER menu appears when the MENU switch is set to SET.
ENG menu:
The ENG menu appears when the MENU switch is set to SET while the SHIFT/ITEM button and UP button are
held down together.
E V A L U A T I ON
K N E E
W . C L I P
M . P E D
V I D E O OU T
:
:
:
:
: O F F O F F
O F F
µ 0 0
Y
S E N S I T I V I T Y ¢
{ |
