Electric connection – PYLE Audio PLDVD140 User Manual
Page 11
11
ELECTRIC CONNECTION
BLACK
WHITE
RED
WHITE
RED
FL_OUT
GREY
FR_OUT
GREY
RL_OUT
BLACK
RR_OUT
BLACK
CENTER_OUT
BROWN
MEMOR
Y
BACK-UP(YELLOW)
ACC(RED)
GND(BLACK)
AMP
CONTROL(GREEN)
YELLOW WHITE
RED
YELLOW
WHITE
RED
VIDEO 2 IN
AUDIO 2 L
IN
AUDIO 2 R IN
VIDEO 2 OUT
YELLOW
DIGIT
AL
AUDIO
REMOTE CONTROL
RECEIVER
(OPTIONAL)
GREEN
SUB WOOFER
