Overview
16
User Manual
1.3
Connection Example
1.3.1
Connection Example
This diagram shows you a connection example including optional equipment.
To ISDN (BRI) port 1-2 (initial)
To ISDN (BRI) port 3 (additional)
(Lightning Protectors)
12 Extension lines
Door Openers
External Music Source
Amplifier
Speaker
Printer
or
Computer
Single Line Telephone
Cordless Phone
Facsimile
Voice Processing System
Car Batteries
Doorphones
KX-T30865
Panasonic
Panasonic
Panasonic
Second Ringer Relay
External Relay
: needs optional card.
1 Analogue CO Line (optional)
3 ISDN (BRI) Lines
KX-T7433
KX-T7431
KX-T7436
KX-T7440
POWER
VOICE PROCESSING SYSTEM KX-TVP50
