12 Hurricane
Left and Right Turn Signal Buttons
Use these buttons to turn on the left and right turn signal (amber) lights.
n Push the appropriate turn signal button once to turn on the signal light before turning your scooter. Your
Hurricane’s turn signals are timed to shut off automatically.
Horn Button
This button activates a warning horn.
n Ensure the key is fully inserted into the key switch and press the horn button to sound the horn.
Battery Condition Meter
When your Hurricane’s key is fully inserted, this meter indicates the approximate battery voltage strength. For
further information on battery charging, see V. “Batteries and Charging.”
Speed Adjustment Dial
This dial allows you to select and limit your Hurricane’s speed up to the highest speed you set with the 4 - 8 mph
switch (6.4 - 12.8 km/hr).
n Set the speed between the slowest (image of the tortoise) and the fastest (image of the hare) speed settings.
Key Switch
This switch enables you to power up and power down your Hurricane.
n Fully insert the key into the key switch to power up your Hurricane.
n Pull the key out to power down your Hurricane.
WARNING! If you remove the key from the key switch while your Hurricane is in motion, the
electronic brakes engage and your Scooter comes to an abrupt stop!
I V . D E S C R I P T I O N
Figure 6. Control Console Assembly
Battery Condition Meter
Key Switch
Horn Button
Light Switch
Speed Adjustment Dial
Throttle Control Lever (Reverse)
Tiller Adjustment Lever
Right Turn Signal Button Left Turn Signal Button
Throttle Control Lever (Forward)
Hazard Light Switch
4 - 8 MPH Switch
