Poulan C38D - Manual (Page 15)

15
CU
T A
LO
NG
D
O
CUT ALONG DO
TT
ED
LIN
E
TTED LINE
BO BO
TT TT
OM EDGE OM EDGE
INSIDE EDGE
2"
1-1/4"
TOP EDGE
R
I
G
H
T
E
D
G
E
MOWER DECK BAFFLE
DRILL TEMPLATE
USE TEMPLATE ABOVE FOR A GUIDE TO DRILLING
YOUR MOWER DECK BAFFLE. CUT OUT SHADED AREA
AND ALIGN WITH TOP, AND RIGHT, EDGE OF BAFFLE.
DRILL A 13/32" HOLE AT SPECIFIED LOCATION.
USE TRIANGLE ABOVE FOR A GUIDE TO TRIMMING
YOUR DEFLECTOR SHIELD. CUT OUT SHADED
AREA AND PLACE ON INSIDE BOTTOM EDGE OF
DEFLECTOR. TRIM DEFLECTOR ALONG DOTTED
LINE USING EITHER HEAVY SHEARS OR A HAND
SAW.
DEFLECTOR TRIM TEMPLATE
