Electric Connection
3
Electric Connection
FRONT.L FRONT.L
FRONT.R FRONT.R
REAR.L REAR.L
REAR.R REAR.R
White/Black White/Black
Gray Gray
To front left
speaker
To front left
speaker
To front right
speaker
To front right
speaker
To rear left
speaker
To rear left
speaker
To rear right
speaker
To rear right
speaker
Green Green
Lgnition wire(Red) Lgnition wire(Red)
Battery wire(Yellow) Battery wire(Yellow)
Ground wire(Black) (To car chassis) Ground wire(Black) (To car chassis)
Car fuse
box
Car fuse
box
Battery Battery
Car fuse box
(Main fuse)
Car fuse box
(Main fuse)
Lgnition key
sw tch i
Lgnition key
switch
Connect to control for antenna
or remote control for amplifier.
Connect to control for antenna
or remote control for amplifier. (Blue) (Blue)
RED RCH out RED RCH out
WHITE LCH out WHITE LCH out
YELLOW VIDEO YELLOW VIDEO
CAR ANTENNA CAR ANTENNA
White White
Gray/Black Gray/Black
Green/Black Green/Black
Purple Purple
Purple/Black Purple/Black
