KNOW YOUR SCROLL SAW
Variable speed control knob
Blade guard foot lock knob
Upper arm
Blade guard foot
Quick release tension lever
Blade storage
Tension knob
Stand
Blade lock knob
Sawdust collection port
ON/OFF switch
Work light
Table lock knob
Bevel scale
Blade
Worktable
Work light
ON/OFF switch
Sawdust blower
Mounting holes
