Specifications
Temperature Range: 40–100°F (4.4–37.8°C)
Pressure Range: 30–125 psi (2.1–8.62 bar)
Service Flow Rate @ 60 psi (4.1 bar): 0.6 gpm (2.3 L/min)
Rated Service Life:
1,000 gallons (3,785L)
Dimensions: 9.18 in. x 4.70 in. x 12.72 in.
(233 mm x 119 mm x 323 mm)
Weight: 6 lbs. (2.7 kg) (filled with water)
Parts Included
• Filter system with filter cartridges – P-250 Cartridge Set
• Installation hardware
(mounting screws, T-Adapter, quick-connect elbows)
• Electronic monitor and 9-volt battery
• Housing wrench
• Lead-free drinking water faucet
• 1/4" plastic tubing
Precautions
WARNING: Do not use with water that is microbiologically unsafe
or of unknown quality without adequate disinfection before or after
the system. Systems certified for cyst reduction may be used on
disinfected waters that may contain filterable cysts.
CAUTION: Filter must be protected against freezing, which can
cause cracking of the filter and water leakage.
CAUTION: The rubber O-ring provides the water-tight seal between
the cap and the bottom of the housing. It is important that the O-ring
be properly seated in the groove below the threads of the housing or a
water leak could occur.
CAUTION: Because of the product’s limited service life and to
prevent costly repairs or possible water damage, we strongly
recommend that the bottom of all plastic housings be replaced every
ten years. If the bottom of your housing has been in use for longer
than this period, it should be replaced immediately. Date the bottom of
any new or replacement housing to indicate the next recommended
replacement date.
Tools and Materials
Required
• Safety glasses
• Hand or electric drill
(cordless recommended)
• 1/4" drill bit
• File
• Phillips head screwdriver
• Adjustable wrench or 7/16”
open-end wrench
• Tube cutters or utility knife
If sink does not have hole
for separate faucet:
• Center punch
• 3/4" drill bit or hole saw
NOTE:
• For cold water use only.
• Make certain that installation complies with all state and local
laws and regulations.
• The contaminants or other substances removed or reduced by
the selected cartridge are not necessarily in your water. Ask your
local water municipality for a copy of their water analysis, or have
your water tested by a reputable water testing lab.
• After prolonged periods of non-use (such as during a vacation) it
is recommended that the system be flushed thoroughly. Let water
run for 5–6 minutes before using.
• The filter cartridges used with this system have a limited service
life. Changes in taste, odor, and/or flow of the water being filtered
indicate that the cartridge should be replaced.
About Your PENTEK Dual Filtration
System
Thank you for purchasing a PENTEK Dual Filtration System. With only
minimal maintenance, your new system will provide you with safer,
better-tasting water for years to come. The filter cartridges should be
changed after every 1,000 gallons of use or once every twelve months,
whichever comes first. Filter life will vary depending on usage and
water conditions. Changes in taste, odor, and/or flow of the water
being filtered indicate that the filter cartridges should be replaced.
The Model US-1500 is Tested and Certified by NSF
International against NSF/ANSI Standard 42 for the reduction
of Taste and Odor, Chlorine, and Particulate Class I. Standard
53 for the reduction of Lead, Mercury, VOC, Cyst, Asbestos,
and Turbidity.
Monitored Dual Filtration System
Installation and Operating Instructions
Model US-1500 (with electronic monitor)
146600 JA05
