15
Connecting a microphone
When the microphone is mounted on
the viewfinder (optional accessory)
for use
The microphone of the microphone kit AJ-MC700 (optional
accessory) can be mounted on the viewfinder.
1
Open the microphone holder.
Microphone
holder
2
Mount the microphone and tighten up the clamp screw.
Clamp screw
3
Connect the microphone cable to the front MIC1
connector on the camera.
Front MIC1 connector
4
If the audio channel whose signals are to be recorded
so requires, set the MIC1 selector switch to FRONT
MIC.
MIC1 selector switch
