14
Performing the viewfinder adjustments
(The viewfinder is an optional accessory.)
Left or right position adjustment
1
Loosen the stopper screw.
Viewfinder
Stopper screw
2
Move the viewfinder to the left or right to adjust its
position.
3
Tighten the stopper screw.
Stopper screw
Forward or backward position
adjustment
1
Rotate the viewfinder forward/backward position fixing
lever towards the outside to release it from the locked
position.
Viewfinder forward/backward
position fixing lever
Viewfinder
2
Move the viewfinder forward or backward to adjust its
position.
3
Rotate the viewfinder forward/backward position fixing
lever in the opposite direction until it locks.
Viewfinder forward/backward
position fixing lever
