The I2C pins are provided through a Philips PCA9512 driver chip. 10kΩ
pull
ht side
Standard RS232 DSub 9 connector
(male like on a computer)
1 NC 6 NC
2 Receive data 7 Request To Send
3 Transmit data 8 Clear To Send
4 NC 9 NC
5 GND
-ups are connected to A. SCL and SD
Rig
The RS232 connector is the same as the ones found on any computer.
SOS button
A button is dedicated to restore default IP address or factory settings.
There are tow possible scenarios:
ƒ If you press it while the device is running, the IP address will be
r l TC tions a
have to send the Save Settings command to the device in order to save it
into EEPROM.
estored as soon as al P connec re closed. Warning: you
and
factory settings of all parameters will be restored AND saved into
EEPROM. In this case, you do not need to send the Save Parameters
command.
ƒ If the button is pressed during startup, the default IP address
