SUBNET MASK
Register Address Register Name Function Read/Write Control
0x13 SUBNETMASK IP subnet mask Read/Write
Register Size Register structure Unit
4 Bytes 4 x Unsigned Bytes none
Description:
Network IP subnet mask used for TCP/IP and UDP/IP.
Notes:
The module will change for a new subnet mask only when all of its
communications ports are closed.
Do not forget to use a SAVEUSERPARAMETERS command.
If you do not want to use subnets, use the following subnet mask when IP
address byte 0 is:
>0 and <=127 :
255.0.0.0 (Class A addresses)
>127 and <=191 : 255.255.0.0 (Class B addresses)
>191 and <=223 : 255.255.255.0 (Class C addresses)
Default value:
255.255.0.0
Example:
For the IP=10.2.6.45 and subnet mask = 255.255.0.0:
IP address class = A Æ netID = 10, subNetID = 2 and hostID = 6.45
