OUTPUTS
Register Address Register Name Function Read/Write Control
0x23 OUTPUTS Sets outputs states Read/Write
Register Size Register structure Unit
2 Bytes Unsigned Int 16 bits, each bit independent none
Description:
Controls the state of each of the output pins.
Bit 0 OUTPUT#1 (Relay A)
Bit 1 OUTPUT#2 (Relay B)
Bit 2 OUTPUT#3
Bit 3 OUTPUT#4
Bit 4 OUTPUT#5
Bit 5 OUTPUT#6
Bit 6 OUTPUT#7
Bit 7 OUTPUT#8
Bit 8 OUTPUT#9
Bit 9 OUTPUT#10
Bit 10 OUTPUT#11
Bit 11 OUTPUT#12
Bit 12 OUTPUT#13
Bit 13 OUTPUT#14
Bit 14 OUTPUT#15
Bit 15 OUTPUT#16
Example:
b'0000 0000 0000 0111' Æ Outputs number 1, 2 and 3 are high and others
are low.
