18.4 Package related soldering information
[1] All surface mount (SMD) packages are moisture sensitive. Depending upon the moisture content, the
maximum temperature (with respect to time) and body size of the package, there is a risk that internal
or external package cracks may occur due to vaporization of the moisture in them (the so called
popcorn effect). For details, refer to the Drypack information in the
Data Handbook IC26; Integrated
Circuit Packages; Section: Packing Methods .
[2] For SDIP packages, the longitudinal axis must be parallel to the transport direction of the
printed-circuit board.
[3] These packages are not suitable for wave soldering as a solder joint between the printed-circuit board
and heatsink (at bottom version) can not be achieved, and as solder may stick to the heatsink (on top
version).
[4] If wave soldering is considered, then the package must be placed at a 45
°
angle to the solder wave
direction. The package footprint must incorporate solder thieves downstream and at the side corners.
[5] Wave soldering is only suitable for LQFP, QFP and TQFP packages with a pitch (e) equal to or larger
than 0.8 mm; it is definitely not suitable for packages with a pitch (e) equal to or smaller than 0.65 mm.
[6] Wave soldering is only suitable for SSOP and TSSOP packages with a pitch (e) equal to or larger than
0.65 mm; it is definitely not suitable for packages with a pitch (e) equal to or smaller than 0.5 mm.
Table 35: Suitability of IC packages for wave, reflow and dipping soldering methods
Mounting Package Soldering method
Wave Reflow [1] Dipping
Through-hole
mount DBS, DIP, HDIP, SDIP, SIL suitable [2] −
suitable
Surface mount BGA, LFBGA, SQFP,
TFBGA not suitable suitable
−
HBCC, HLQFP, HSQFP,
HSOP, HTQFP, HTSSOP,
SMS not suitable [3] suitable
−
PLCC [4] , SO, SOJ suitable suitable
−
LQFP, QFP, TQFP not recommended [4] [5] suitable
−
SSOP, TSSOP, VSO not recommended [6] suitable
−
