Philips Semiconductors
ISP1122
USB stand-alone hub
Product specification Rev. 03 — 29 March 2000 33 of 48
9397 750 07002 © Philips Electronics N.V. 2000. All rights reserved.
[1] Operating modes 0, 1, 4 and 5; see Table 4 .
[1] Test circuit: see Figure 22 .
[2] Excluding the first transition from Idle state.
[3] Characterized only, not tested. Limits guaranteed by design.
Table 31: Dynamic characteristics: overcurrent sense pins
V
CC
= 4.0 to 5.5 V; V
GND
= 0 V; T
amb
=
−
40 to
+
85
°
C; unless otherwise specified.
Symbol Parameter Conditions Min Typ Max Unit
t
trip
overcurrent trip response time
from OCn LOW to PSWn HIGH see Figure 14 [1]
- - 15 ms
Table 32: Dynamic characteristics: analog I/O pins (D
+
, D
−
); full-speed mode [1]
V
CC
= 4.0 to 5.5 V; V
GND
= 0 V; T
amb
=
−
40 to
+
85
°
C; C
L
= 50 pF; R
PU
= 1.5 k
Ω
on D
+
to V
TERM
.; unless otherwise specified.
Symbol Parameter Conditions Min Typ Max Unit
Driver characteristics
t
FR
rise time C
L
= 50 pF;
10 to 90% of
|
V
OH
−
V
OL
|
4 - 20 ns
t
FF
fall time C
L
= 50 pF;
10 to 90% of
|
V
OH
−
V
OL
|
4 - 20 ns
FRFM differential rise/fall time
matching (t
FR
/t
FF
)
[2] 90 - 111.11 %
V
CRS
output signal crossover voltage [2] [3] 1.3 - 2.0 V
Data source timing
t
DJ1
source differential jitter for
consecutive transitions see Figure 15 [2] [3] −
3.5 -
+
3.5 ns
t
DJ2
source differential jitter for
paired transitions see Figure 15 [2] [3] −
4 -
+
4 ns
t
FEOPT
source EOP width see Figure 16 [3] 160 - 175 ns
t
FDEOP
source differential data-to-EOP
transition skew see Figure 16 [3] −
2 -
+
5 ns
Receiver timing
t
JR1
receiver data jitter tolerance for
consecutive transitions see Figure 17 [3] −
18.5 -
+
18.5 ns
t
JR2
receiver data jitter tolerance for
paired transitions see Figure 17 [3] −
9 -
+
9 ns
t
FEOPR
receiver SE0 width accepted as EOP;
see
Figure 16
[3] 82 - - ns
t
FST
width of SE0 during differential
transition rejected as EOP;
see
Figure 18
[3] - - 14 ns
Hub timing (downstream ports configured as full-speed)
t
FHDD
hub differential data delay
(without cable) see Figure 19 ;
C
L
= 0 pF
[3] - - 44 ns
t
FSOP
data bit width distortion after
SOP see Figure 19 [3] −
5 -
+
5 ns
t
FEOPD
hub EOP delay relative to t
HDD
see Figure 20 [3] 0 - 15 ns
t
FHESK
hub EOP output width skew see Figure 20 [3] −
15 -
+
15 ns
