USB stand-alone hub
Product specification Rev. 03 — 29 March 2000 4 of 48
9397 750 07002 © Philips Electronics N.V. 2000. All rights reserved.
OC2 8 AI/I overcurrent sense input for downstream port 2 (analog [5] )
OC3 9 AI/I overcurrent sense input for downstream port 3 (analog [5] )
OC4 10 AI/I overcurrent sense input for downstream port 4 (analog [5] )
OC5/GOC [3] 11 AI/I modes 5, 7: overcurrent sense input for downstream port 5
(analog
[5] )
modes 0, 1, 3: global overcurrent sense input (analog [5] )
DM4 12 AI/O downstream port 4 D
−
connection (analog) [4]
DP4 13 AI/O downstream port 4 D
+
connection (analog) [4]
SP/BP 14 I selects power mode:
self-powered: connect to V
DD
(local power supply); also use
this mode for hybrid-powered operation
bus-powered: connect to GND; disable downstream port 5 to
meet supply current requirements
[4]
HUBGL 15 O hub GoodLink LED indicator output (open-drain, 6 mA);
to connect an LED use a 330
Ω
series resistor; if unused
connect to V
CC
via a 10 k
Ω
resistor
PSW3/GL3 [3] 16 O modes 4 to 6: power switch control output for downstream
port 3 (open-drain, 6 mA)
modes 0 to 3, 7: GoodLink LED indicator output for
downstream port 3 (open-drain, 6 mA); to connect an LED
use a 330
Ω
series resistor
PSW4/GL4 [3] 17 O modes 4 to 6: power switch control output for downstream
port 4 (open-drain, 6 mA)
modes 0 to 3, 7: GoodLink LED indicator output for
downstream port 4 (open-drain, 6 mA); to connect an LED
use a 330
Ω
series resistor
PSW5/GL5/
GPSW
[3]
18 O mode 5: power switch control output for downstream port 5
(open-drain, 6 mA)
modes 3, 7: GoodLink LED indicator output for downstream
port 5 (open-drain, 6 mA); to connect an LED use a 330
Ω
series resistor
modes 0 to 2: gang mode power switch control output
(open-drain, 6 mA)
XTAL1 19 I crystal oscillator input (6 MHz)
XTAL2 20 O crystal oscillator output (6 MHz)
RESET [2] 21 I reset input (Schmitt trigger); a LOW level produces an
asynchronous reset; connect to V
CC
for power-on reset
(internal POR circuit)
OPTION/SCL 22 I/O mode selection input; also functions as I 2 C-bus clock output
(open-drain, 6 mA)
INDV/SDA 23 I/O selects individual (HIGH) or global (LOW) power switching
and overcurrent detection; also functions as bidirectional
I
2 C-bus data line (open-drain, 6 mA)
DM5 24 AI/O downstream port 5 D
−
connection (analog) [4]
DP5 25 AI/O downstream port 5 D
+
connection (analog) [4]
DM1 26 AI/O downstream port 1 D
−
connection (analog) [6]
