16 www.pridemobility.com Jazzy 610
I I I . Y O U R P O W E R C H A I R
JAZZY 610 SPECIFICATIONS
Suspension: Active-Trac Extreme (ATX)
Drive Wheels: 10 in., pneumatic (10 in. solid optional)
Front Caster Wheels: 5 in., solid
Rear Caster Wheels: 6 in., solid
Maximum Speed:¹ Up to 4 mph
Brakes: “Intelligent Braking” electronic regenerative, disc park brake
Ground Clearance:² 2.125 in.
Turning Radius:² 21.25 in.
Overall Size:² Length: 39 in. (with foot platform)
Width: 23.25 in.
Seating Options: Medium-back Seat (standard)
Limited Recline High-Back Seat (optional)
Full Recline High-back Seat (optional)
Power Elevating Seat (optional)
Drivetrain: Two motor, mid-wheel drive
Batteries:³ Two 12-volt, U-1 batteries
Battery Charger: 4-amp, onboard (standard)
4-amp onboard/5-amp off-board combo (optional)
Electronics: 50-amp PG Drives VSI Controller (standard)
75-amp Dynamic FLIGHT Controller (optional)
Weight Capacity: 300 lbs.
Component Weights: Base: 108.5 lbs. (without seat and batteries)
Medium-back Seat: 37 lbs.
Batteries: 25.5 lbs. each
¹Varies with user weight, terrain type, battery amp hour rating (AH), battery charge, battery condition, and tire condition.
²Due to manufacturing tolerances and continued product improvement, this specification can be subject to variance of
(+ or – ) 3%.
³AGM or Gel-Cell type recommended.
NOTE: All specifications subject to change without notice.
