I I I . Y O U R P O W E R C H A I R
THE JAZZY 610
The Jazzy 610 has two main assemblies: the seat assembly and the power base assembly. See figure 5. Typically, the seat
assembly includes the armrests, seatback, and seat base. The power base assembly includes two motor/brake assemblies,
two drive wheels, four caster wheels, two batteries, and wiring harnesses. See figure 5, 6, and 7.
SEATBACK
REAR
SHROUD
DRIVE WHEEL
CASTER WHEEL
Figure 5. The Jazzy 610
POWER BASE
ASSEMBLY
SEAT ASSEMBLY
JOYSTICK
FOOT RIGGING
(FOOT PLATFORM SHOWN)
SEAT BASE
ARMRESTS
CONTROLLER
(VSI SHOWN)
CASTER WHEEL
