Philips Semiconductors Product specification
SA7016 1.3GHz low voltage fractional-N synthesizer
1999 Nov 04 12
Data format
Table 1. Format of programmed data
LAST IN MSB SERIAL PROGRAMMING FORMAT FIRST IN LSB
p23 p22 p21 p20 ../.. ../.. p1 p0
Table 2. A word, length 24 bits
LAST IN MSB LSB FIRST IN
Address fmod Fractional-N Main Divider ratio Spare
0 0 FM NF2 NF1 NF0 N15 N14 N13 N12 N11 N10 N9 N8 N7 N6 N5 N4 N3 N2 N1 N0 SP1 SP2
Default: 0 0 1 0 0 0 1 0 0 0 1 0 0 0 1 1 0 0 0 0 0 0
A word select Fixed to 00.
Fractional Modulus select FM 0 = modulo 8, 1 = modulo 5.
Fractional-N Increment NF2..0 Fractional N Increment values 000 to 111.
N-Divider N0..N15, Main divider values 512 to 65535 allowed for divider ratio.
Table 3. B word, length 24 bits
Address REFERENCE DIVIDER LOCK PD CP FRACTIONAL COMPENSATION DAC SPARE
0 1 R9 R8 R7 R6 R5 R4 R3 R2 R1 R0 LO MAIN CP0 FC7 FC6 FC5 FC4 FC3 FC2 FC1 FC0 SP3
Default: 0 0 0 1 0 1 0 0 0 1 0 0 0 0 1 0 1 0 0 0 0 0
B word select Fixed to 01
R-Divider R0..R9, Reference divider values 4 to 1023 allowed for divider ration.
Charge pump current
Ratio CP0: Charge pump current ratio, see table of charge pump currents.
Lock detect output L0
0
Main lock detect signal present at the LOCK pin (push/pull).
1 Main lock detect signal present at the LOCK pin (open drain).
When main loop is in power down mode, the lock indicator is low.
Power down Main = 1: power to main divider, reference divider, main charge pumps, Main = 0 to power down.
Fractional Compensation FC7..0 Fractional Compensation charge pump current DAC, values 0 to 255.
Table 4. D word, length 24 bits
Address SYNTHESIZER TEST
BITS
SYNTHESIZER TEST BITS
1 1 0 – – – – – Tspu – – – – – – – – – – – – – – –
Default: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Tspu: Speed up = 1 Forces the main charge pumps in speed-up mode all the time.
NOTE: All test bits must be set to 0 for normal operation.
