ILS 1294H
A PRODUCT OF PEAVEY ELECTRONICS CORP.
TM
WARNING:
CONSULT SPEC SHEET FOR FULL SUSPENSION
RATINGS. DO NOT EXCEED 400 lbs. OR 45 DEGREE ANGLE
6,059,069 AND 6,064,745
FULL R ANGE BIAMP
750W RMS CONT.
8 OHMS
LF: 500W RMS CONT.
8 OHMS
HF:100W RMS CONT.
>1.0 kHz
8 OHMS
ALL CONNECTORS ARE WIRED IN PARALLEL INTERNALLY.
CHANGE INTERNAL JUMPER FOR BIAMP OR FULL RANGE
OPERATION.
1+ 1 N.C. 2+ 2 - -
BUILT UNDER U.S. PATENT NOS.
BIAMP
1+: LF+
1-: LF-
2+: HF+
2-: HF-
FULL RANGE
1+(+), 1-(-)
2+(NC), 2-(NC)
ILS ™ 1294H INPUT
