-37-
A.3 Fiber Optical Cable Connection Parameter
The wiring details are as below:
Fiber Optical patch Cables:
Standard Fiber Type Cable Specification
100Base-FX
(1300nm)
Multi-mode 50/125µm or 62.5/125µm
Multi-mode 50/125µm or 62.5/125µm 100Base-FX
(1310nm) Single-mode 9/125µm
100Base-BX-U
(TX :1310/RX :1550)
100Base-BX-D
(TX :1550/RX :1310)
Single-mode 9/125µm
A.4 Power Information
The power jack of FT-90X is with 2.5mm in the central post and required +5VDC power input. It will conform to the bundled
AC-DC adapter and Planet’s Media Chassis. Should you have the problem to make the power connection, please contact
your local sales representative.
Please keep the AC-DC adapter as spare parts when your FT-90X is installed to a Media Chassis.
2.5mm
DC Receptacle 2.5mm
+5V for each slot
DC receptacle is 2.5mm wide that conforms to and matches the Media Converter 2.5mm DC
jack's central post. Do not install any improper unit, model of the Media Converter
A.4 Available Modules
The following list the available Modules for FT-905A
MFB-FX
SFP-Port 100Base-FX Transceiver (1310nm) -2KM
MFB-F20
SFP-Port 100Base-FX Transceiver (1310nm) - 20KM
MFB-FA20
SFP-Port 100Base-BX Transceiver (WDM,TX:1310nm) -20KM
MFB-FB20
SFP-Port 100Base-BX Transceiver (WDM,TX:1550nm) -20KM
2080-AA3450-000
