OnSite Series Quick Start Guide 3
1.0 Unpacking and Installation
1. Check the contents of the shipping container and accessories box or bag against the content list and the
packing slip. Verify that you received all listed equipment and inspect all items for shipping damage.
2. Unpack the OS-10 Series chassis and install it into a rack according to the instructions in the OnSite Series
User Manual available online at www.patton.com/manuals/OS10xx.pdf.
3. Verify that the site where you wish to install and operate the equipment conforms to the environmental
requirements in the OnSite Series User Manual.
2.0 Powering Up the System
If your OS-10 Series system was ordered for use with AC power, follow these steps:
1. Connect the enclosed AC power cable to the AC power receptacle on the rear side of the OS-10 Series
chassis.
2. Connect the power cable plug to an AC power source with the following characteristics: 15 A at 120 VAC
(60 Hz) or 10 A at 240 VAC (50 Hz) circuit with overcurrent protection.
Refer to the OS-10 Series Installation and Operation Guide if your system was ordered for use with DC power (–
48 VDC nominal).
When you first apply power to the system, the STAT (status) LED on the front panel becomes a solid amber light.
This light indicates that the system is booting. The STAT LED becomes a solid green light when the system com-
pletes the boot process and is ready for management access and operation.
Electrostatic Discharge (ESD) can damage equipment and impair electrical
circuitry. It occurs when electronic printed circuit cards are improperly
handled and can result in complete or intermittent failures. Do the follow-
ing to prevent ESD:
• Always follow ESD prevention procedures when removing and replac-
ing cards.
• Wear an ESD-preventive wrist strap, ensuring that it makes good
skin contact. Connect the clip to an unpainted surface of the chassis
frame to safely channel unwanted ESD voltages to ground.
• To properly guard against ESD damage and shocks, the wrist strap
and cord must operate effectively. If no wrist strap is available,
ground yourself by touching the metal part of the chassis.
CAUTION
