Page 19
Connections when one unit is used
Set the CONTROL switch on the front panel to LOCAL.
Audio monitor output connectors
Analog video input connectors
Reference input connectors
Digital audio/video
input connector
Digital audio
output
Digital audio/video output
Analog audio input connectors
connector
Digital audio
input connector
Active through output
connector
Analog audio output connectors
Video monitor output connectors
- 1 9 -
