PBM-070L
Installation Manual Page - 4 -
Projector Bracket Installation
M8 x12mm Phillips
Head Screws
Projector Bracket
Projector
Screwdriver
M8 x12mm Phillips
Head Screws
Step 1. Invert the projector and place it on a soft and flat surface.
Remove any foot levelers that might possibly prevent the
correct installation of the bracket.
Step 2. Locate the eight mounting points located on the bottom of
the projector.
Step 3. Line up the mounting points on the projector with the
mounting holes on the mounting bracket.
Step 1. Using a screwdriver, secure the mounting bracket using
eight (8) M8 x 12mm Phillips Head screws.
Do not over-tighten these screws. Over-tightening
the screws may result in damaging the threaded
inserts on the projector.
