Premier Mounts PBM-070L - Manual (Page 2)

PBM-070L
Installation Manual Page - 2 -
Table of Contents
WARNING STATEMENTS.............................................................................................................................................................. - 2 -
PARTS LIST ....................................................................................................................................................................................... - 3 -
INSTALLATION TOOLS ................................................................................................................................................................. - 3 -
PROJECTOR BRACKET INSTALLATION.................................................................................................................................. - 4 -
CEILING INSTALLATION.............................................................................................................................................................. - 5 -
PROJECTOR ADJUSTMENT ......................................................................................................................................................... - 7 -
TECHNICAL SPECIFICATIONS ................................................................................................................................................... - 8 -
WARRANTY ...................................................................................................................................................................................... - 9 -
Warning Statements
THE CEILING STRUCTURE MUST BE CAPABLE OF SUPPORTING AT LEAST FIVE (5) TIMES THE WEIGHT OF THE
PROJECTOR. IF NOT, THE CEILING MUST BE REINFORCED. PROPER INSTALLATION PROCEDURE BY A QUALIFIED
SERVICE TECHNICIAN, AS OUTLINED IN THE INSTALLATION INSTRUCTIONS, MUST BE ADHERED TO. FAILURE TO
DO SO COULD RESULT IN SERIOUS PERSONAL INJURY, OR EVEN DEATH. THE MAXIMUM WEIGHT THAT CAN BE
USED WITH THIS PROJECTOR IS 200LBS.
SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE INSTALLATION OF THIS PRODUCT. USE
PROPER SAFETY GEAR AND TOOLS FOR THE INSTALLATION PROCEDURE TO PREVENT PERSONAL INJURY.
PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS SHOULD BE READ AND
COMPLETELY UNDERSTOOD. THE INSTALLATION INSTRUCTIONS MUST BE READ TO PREVENT PERSONAL INJURY
AND PROPERTY DAMAGE. KEEP THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR
FUTURE REFERENCE.
Indicates that the power plug is to be disconnected
from the power outlet.
Contact Premier Mounts with any questions –
800-368-9700.
Safety precautions must be taken at all times.
Warning and Caution statements.
A secure structure must support the weight, or load, of the projector. When mounting to a ceiling that contains wooden studs, dead
center of the wooden stud must be confirmed prior to installation.
Do not install on a structure that is prone to vibration, movement or chance of impact. Failure to do so could result in damage to the
projector and/or damage to the mounting surface.
Do not install near heater, fireplace, direct sunlight, air conditioning or any other source of direct heat energy. Failure to do so may
result in damage to the projector and could increase the risk of fire.
At least two qualified people should perform the installation procedure. Injury and/or damage can result from dropping or mishandling
the projector.
Recommended mounting surfaces: wooden studs and solid-flat concrete. If the mount is to be installed on any surface other than
wooden studs, use suitable hardware (which is commercially available).
