Additional information 12
111
En
Specifications
Amplifier Section
Continuous average power output of 140 watts* per
channel, min., at 8 ohms, from 20 Hz to 20 000 Hz
with no more than 0.08 %** total harmonic
distortion.
Multi channel simultaneous power output (1 kHz, 1 %, 8 Ω)
7 ch total . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 630 W
Continuous Power Output (20 Hz to 20 kHz, 8 Ω, 0.08 %)
Front. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 W + 140 W
Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 W
Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . 140 W + 140 W
Surround back (Front height/wide) . . . . . . 140 W + 140 W
Continuous Power Output (1 kHz, 6 Ω, 1.0 %)
Front. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 W + 180 W
Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 W
Surround . . . . . . . . . . . . . . . . . . . . . . . . . . . 180 W + 180 W
Surround back (Front height/wide) . . . . . . 180 W + 180 W
Total harmonic distortion . . . . . . . . . . . . . . . . . . . . . . . . 0.05 %
(20 Hz to 20 kHz, 130 W, 8 Ω)
* Measured pursuant to the Federal Trade Commission’s
Trade Regulation rule on Power Output Claims for Amplifiers
** Measured by Audio Spectrum Analyzer
Audio Section
Input (Sensitivity/Impedance)
PHONO MM . . . . . . . . . . . . . . . . . . . . . . . . . . . .5 mV/47 k Ω
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .400 mV/47 k Ω
Output (Level/Impedance)
REC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 400 mV/2.2 k Ω
Signal-to-Noise Ratio (IHF, short circuited, A network)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .103 dB
Frequency Response . . . . . . . . . . . .5 Hz to 100 000 Hz dB
(Pure Direct Mode)
Tuner Section
Frequency Range (FM) . . . . . . . . . . . . . 87.5 MHz to 108 MHz
Antenna Input (FM) . . . . . . . . . . . . . . . . . . . 75
Ω unbalanced
Frequency Range (AM). . . . . . . . . . . . . . 531 kHz to 1602 kHz
Antenna (AM) . . . . . . . . . . . . . . . . . Loop antenna (balanced)
Video Section
Signal level
Composite Video. . . . . . . . . . . . . . . . . . . . . . . 1 Vp-p (75 Ω)
Component Video . . . . . . . . . . . . . . . . . . Y: 1.0 Vp-p (75 Ω),
PB, PR: 0.7 Vp-p (75 Ω)
Corresponding maximum resolution
Component Video . . . . . . . . . . . . . . . . . . . . . .1080p (1125p)
(Video convert off)
Digital In/Out Section
HDMI terminal . . . . . . . . . . . . . . . . . . . . . . . . 19-pin (Not DVI)
HDMI output type . . . . . . . . . . . . . . . . . . . . . . . . . 5 V, 100 mA
USB terminal. . . . . . . . . . . . . . . . USB2.0 Full Speed (Type A)
iPod terminal. . . . . . . . . . . . . . . USB, and Video (Composite)
SIRIUS antenna cable . . . . . . . . . . . . . . 8-pin mini DIN cable
ADAPTER PORT terminal. . . . . . . . . . . . . . . . . . . 5 V, 100 mA
Integrated Control Section
Control (SR) terminal . . . . . . . . . . . .Ø 3.5 Mini-jack (MONO)
Control (IR) terminal . . . . . . . . . . . . .Ø 3.5 Mini-jack (MONO)
IR signal . . . . . . . . . . . . . . . . . High Active (High Level: 2.0 V)
12 V Trigger terminal . . . . . . . . . . . . .Ø
3.5 Mini-jack (MONO)
12 V Trigger output type . . . . . . . . . . . . . . 12 V, Total 150 mA
RS-232C cable type . . . . . . . 9-pin, cross type, female-female
EXTENSION terminal. . . . . . . . . . . . . . . . . . . . . . . 5 V, 150 mA
Network Section
LAN terminal . . . . . . . . . . . . . . . . . . 10 BASE-T/100 BASE-TX
Miscellaneous
Power requirements . . . . . . . . . . . . . . . . . . . .AC 120 V, 60 Hz
Power consumption . . . . . . . . . . . . . . . . . . . . . . . . . . . .330 W
In standby . . . . . . . . 0.2 W (HDMI Setup – Control : OFF)
0.3 W (HDMI Setup – Control : ON)
Dimensions . . . . . . 420 mm (W) x 200 mm (H) x 460 mm (D)
(16 9 / 16 in. (W) x 7 7 / 8 in. (H) x 18 1 / 8 in. (D))
Weight (without package). . . . . . . . . . . . . . . .18.5 kg (40.8 lb)
Number of Furnished Parts
MCACC Setup microphone (APM7009). . . . . . . . . . . . . . . . . 1
Remote control unit (AXD7591) . . . . . . . . . . . . . . . . . . . . . . . 1
AAA size IEC R03 dry cell batteries . . . . . . . . . . . . . . . . . . 2
iPod cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FM wire antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Power cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
These operating instructions
Note
• Specifications and the design are subject to possible
modifications without notice, due to improvements.
Cleaning the unit
• Use a polishing cloth or dry cloth to wipe off dust and
dirt.
• When the surface is dirty, wipe with a soft cloth
dipped in some neutral cleanser diluted five or six
times with water, and wrung out well, and then wipe
again with a dry cloth. Do not use furniture wax or
cleansers.
• Never use thinners, benzene, insecticide sprays or
other chemicals on or near this unit, since these will
corrode the surface.
This product includes FontAvenue ® fonts licenced by NEC corporation.
FontAvenue is a registered trademark of NEC Corporation
