Pride Mobility Victory XL User Manual
Page 23
23
Victory XL/RevD/June03
www.pridemobility.com
Motor/Transaxle Assembly
The motor/transaxle assembly consists of a geared transmission and differential. This one piece, direct drive, fully
sealed assembly provides quiet operation with maximum power and long life. See figure 7.
Anti-Tip Wheels
The anti-tip wheels are an integral and important safety feature of your Victory XL. Do not under any circum-
stances remove the anti-tip wheels from your Victory XL. See figure 7.
WARNING! Do not remove the anti-tip wheels or modify your scooter in any way that is not
authorized by Pride.
V . Y O U R V I C T O R Y X L
