APPENDIX D
LINE RATE & REACH CHART, BASED ON 24 AWG (0.5 MM)
Note
The actual distance and link performance may vary depending
on the environment and type/gauge of wire used.
Note
DS = downstream, US = upstream
Note
This chart applies to Model 2174s with a twisted-pair line inter-
face: Model 2174/EUI and 2174/TB. Contact Patton for Model
2174/BNC rates.
Table 6:
Line Rate & Reach Chart Using Twisted-Pair (Long Range)
Mode
(Long Range)
Distance in Feet
Mbps
ft
m/km
DS
US
Symmetric
250 ft
76 m
68
40
1000 ft
305 m
62
44
2,000 ft
610 m
50
16
3,000 ft
914 m
33
4
5,000 ft
1.5 km
16
2
10,000 ft
3 km
2.5
1
Asymmetric
250 ft
76 m
67
16
1000 ft
305 m
59
16
2,000 ft
610 m
45
11
3,000 ft
914 m
31
5
5,000 ft
1.5 km
17
682 kbps
10,000 ft
3 km
4
263 kbps
