Open the box – Precor S3.15 User Manual
Page 7
S3.15 Assembly and Maintenance Guide
page 7
1
2
3
4
5
6
Open the Box
Open the Box
Use wire tie cutters to open the box.
The illustration shows how the S3.15 will look when
you have completed its assembly. The callouts identify
specific pieces.
Important: Most fasteners are fitted to the frame or
pulleys, you will need to disassemble the fasteners
before proceeding with each step.
Main Base
Top Assembly
Rear Upright
Rear Crossbar
Main Upright
Leg Extension Arm
Weight Stack
Row Handle
Handlebars
Press Arm Assembly
Lat Bar
Leg Extension
Curl Bar
Ankle Strap
Triceps Strap
