12
Settings Using the On Screen
Display
Preparations
– Confirm that the TV is on and the VCR viewing channel is
selected.
– Turn on the VCR.
– Set the VCR/TV switch E to [VCR].
To Set the Colour TV System
1 Press the MENU button U to
display the Main menu on the TV
screen.
2 Press the Cursor buttons (34) S
to select [SYSTEM] then press the
OK button T.
3 Press the Cursor buttons (34) S to select [AUTO].
– The VCR automatically distinguishes between [PAL] or
[NTSC] signals. If the picture lacks colour during AV
external recording or playback, set to [PAL] or [NTSC].
– When you want to record or play back in black and
white, set to [B/W].
4 Press the MENU button U twice to exit the On Screen
Display.
To Make Various Indicators Appear On
Screen Display
At a press of the OSD button P,
the following indications appear
on the TV screen.
– Press the OSD button P again to
make the On Screen Display
disappear.
1 Audio Output Mode Indicators
At each press of the AUDIO button ?, the selected sound
mode is indicated with Left (L) and Right (R).
Stereo: Both the Left (L) and Right (R) Indicators appear.
Left:
The Left (L) Indicator appears
Right: The Right (R) Indicator appears.
Normal: Neither the Left (L) nor Right (R) Indicator
appears.
– At every push of this button, the audio output mode
changes as follows.
During playback:
While the broadcast signals are being received:
SYSTEM
END :MENU
SELECT:
AUTO
PAL
NTSC
B/W
CH 1
L R
STEREO
STANDARD
4 5 6
7
8
9
0:00.22
SP
3 2 1
PAL
On Screen Display
2 STEREO or BILINGUAL indicator (NV-FJ620A)
When receiving a TV programme, the type of sound
system in which it is broadcast is automatically indicated.
STEREO, M1 and M2 Indicator (NV-FJ620EA)
When receiving a TV programme with the Stereo,
Bilingual or NiCAM sound system, the type of sound
system in which it is broadcast is automatically indicated.
STEREO: When receiving a Stereo/NICAM stereo
broadcast.
M1 M2: When receiving a Bilingual/NICAM dual-sound
boadcast.
M1: When receiving a NICAM monaural broadcastl.
– To hear stereo performance connect as shown on page 5
to a TV or Stereo Amplifier with left and right audio inputs.
3 Programme position
4 Tape running display
Stop, Eject
Rewind, Review 6
Fast Forward, Cue 5
Playback 1
Recording ¥
Recording pause ; ¥
Repeat playback R 1
5 Present time/Tape counter/Remaining tape time/ Index
Search/OTR indication/Play-Off Timer
Information Display
Present time 17:24
Tape counter –2:35.47
Remaining tape time REMAIN 2:34
Index Search S 01
OTR indication OTR 60
Play-Off Timer OFF 60
6 Tape speed indicator (SP/LP/EP)
7 Cassette-in indicator
8 Colour system indicator
Any selected colour TV system except [AUTO] appears
on screen display. (See the To Set the Colour TV
System on this page.)
9 Picture mode indicator
At each press of the PICTURE MODE button 5, the
selected picture mode is set and following picture mode
indicators appear.
Example:
STANDARD:
For TV programme recorded
DYNAMIC: For Scenery, Sports
SOFT: For Rental soft tape
CARTOON: For Cartoon
Note:
– The on screen display may be disturbed or disappear
during special playback.
Stereo L R Normal audio track
Stereo L R Normal
