4.1.1 Two-Wire Cable Connection Via RJ-45

A. The RJ-45 jack on a Model 1065 Series Short Range Modem is

prewired for a standard TELCO wiring environment. To be sure you
have the right wiring, use the table below as a guide.

RJ-45

SIGNAL

1 -------------NC
2 -------------GND

3 -------------RCV
4 -------------XMT
5 -------------XMT
6 -------------RCV
7 -------------GND
8 -------------NC

Connection to ground is optional

B. Proper wiring of pairs between the two modems is as follows:

SIGNAL

PIN#

COLOR*

COLOR

PIN#

SIGNAL

XMT

4

Green ------------Green

4

XMT

XMT

5

Red ---------------Red

5

XMT

*Standard color codes—yours may be different

C. AT&T standard modular color codes:

4.2 FOUR-WIRE INSTALLATION

When communicating over a two twisted pair circuit, the Model

1065 can operate full or half duplex, point-to-point or multipoint. In two
pair point-to-point applications, you will need a

pair

of Model 1065s for

each circuit—one at

each end

of the two pair cable. In two pair multi-

point applications you will need three or more Model 1065 units. These
can be connected using a star topology, although a daisy chain topolo-
gy is usually used.

4.2.1 Four-Wire Cable Connection Via RJ-45

A. The RJ-45 jack on a Model 1065 Short Range Modem is

prewired for a standard TELCO wiring environment. To be sure you
have the right wiring, use the table below as a guide.

RJ-45

SIGNAL

1 -------------NC
2 -------------GND

3 -------------RCV
4 -------------XMT
5 -------------XMT
6 -------------RCV
7 -------------GND
8 -------------NC

B. Proper crossing of pairs between the two modems is as fol-

lows:

Connection to ground is optional

SIGNAL

PIN#

COLOR*

COLOR

PIN#

SIGNAL

GND

2

Orange ----------Brown

7

GND

RCV

3

Black -------------Green

5

XMT

XMT

4

Red ---------------Yellow

6

RCV

XMT

5

Green ------------Black

3

RCV

RCV

6

Yellow ------------Red

4

XMT

GND

7

Brown ------------Orange

2

GND

*Standard color codes—yours may be different

Connection to ground is optional

1 - Blue
2 - Orange
3 - Black
4 - Red
5 - Green
6 - Yellow
7 - Brown
8 - Slate
