51
En
12
Additional Information
Front speaker
Enclosure .................................... Closed-box bookshelf type
(magnetically shielded †)
System ................................................... 10 cm 2-way system
Speaker
Woofer ................................................. 10 cm cone type
Tweeter .............................................. 5.2 cm cone type
Nominal impedance ........................................................ 8
Ω
Frequency range ........................................ 50 to 20,000 Hz
Max. input .................................................................... 115 W
Dimensions ...................... 145 (W) x 235 (H) x 204 (D) mm
Weight ........................................................................... 2.0 kg
Surround speaker
Enclosure .................................... Closed-box bookshelf type
System .................................................. 8.7 cm 1-way system
Speaker .................................................. 8.7 cm (cone type)
Nominal impedance ........................................................ 6
Ω
Frequency range ...................................... 150 to 20,000 Hz
Max. input ...................................................................... 52 W
Dimensions ......................... 110 (W) x 155 (H) x 76 (D) mm
Weight ........................................................................... 0.8 kg
Center speaker
Enclosure .................................... Closed-box bookshelf type
(magnetically shielded †)
System .................................................. 8.7 cm 1-way system
Speaker ................................................. 8.7 cm (cone type)
Nominal impedance ........................................................ 6
Ω
Frequency range ........................................ 70 to 20,000 Hz
Max. input ..................................................................... 52 W
Dimensions ......................... 310 (W) x 110 (H) x 76 (D) mm
Weight ........................................................................... 1.0 kg
Subwoofer
Enclosure .............................................. Bass reflex floor type
System .................................................. 16 cm 1-way system
Speaker ................................................... 16 cm (cone type)
Nominal impedance ........................................................ 8
Ω
Frequency range ...................................... 30 Hz to 2000 Hz
Max. input .................................................................... 115 W
Dimensions ..................... 10 (W) x 360 (H) x 327 (D) mm
Weight ........................................................................... 4.8 kg
† Antimagnetic design (EIAJ) speaker system conforms to the basic
EIAJ standards.
Supplied Items
Remote control .................................................................... 1
AA/R6P dry cell batteries ................................................... 2
AM loop antenna ................................................................. 1
FM antenna .......................................................................... 1
Video cord (yellow) ............................................................. 1
Power cord ............................................................................ 1
................ 2 (Central and South America models only)
Speaker cords
5m (for front L-R speakers) ....................................... 2
5m (for center speaker) ............................................. 1
10m (for Surround L-R speakers) .............................. 2
5m (for subwoofer) ................................................... 1
Operating instructions ........................................................ 1
Non-slip pads .................................................................... 20
Warranty card (European and Australian models only) .... 1
Power plug adapter (For Taiwan, the Philippines, Saudi Arabia,
the Near East, American PX, Japanese tax-exempt export
models and Central & South American models) ................. 1
Note: Specifications and design subject to possible modification
without notice, due improvements.
Specifications
Amplifier Section
Continuous power output (RMS)
Front ................................................. 87 W, per channel
(1 kHz, 10 % T.H.D., 8
Ω
)
Surround .......................................... 33 W, per channel
(1 kHz, 10 % T.H.D., 6
Ω
)
Center ............................................... 33 W, per channel
(1 kHz, 10 % T.H.D., 6
Ω
)
Subwoofer .................. 87 W (100Hz, 10% T.H.D., 8
Ω
)
DVD Player (Audio)Section
S/N ratio ............................................................. 5 dB (EIAJ)
Dynamic range ................................................... 5 dB (EIAJ)
Distortion ................................................................. 0.004%
Frequency response
48 kHz sampling .................................. 4 Hz to 22 kHz
6 kHz sampling .................................. 4 Hz to 44 kHz
Wow & flutter ................................. Below measurable levels
(
±
0.001% W.PEAK)
DVD Player (Video) Section
Output level ................................................... 1 Vp-p (75
Ω
)
Video output level ...................................... 1 Vp-p (75
Ω
)
Video C output level ............................... 286 mVp-p (75
Ω
)
DVD (Other jacks) Section
Digital coaxial input (PCM/2/DTS) ...... Coaxial connector
Tuner Section
FM tuner
Frequency range .................... 87.5 MHz to 108.0 MHz
Antenna ............................................. 75
Ω
unbalanced
AM tuner
Frequency range
............................ 531 kHz to 1,602 kHz ( kHz step)
........................ 530 kHz to 1,700 kHz (10 kHz step)
Antenna ................................. loop antenna (supplied)
Power Supply Section
Power Requirements
Multi voltage model
.................. AC 110-127/220-230/240 V (Switchable)
, 50/60 Hz
European model ................... AC 220-230 V, 50/60 Hz
K model ..................................... AC 230 V, 50/60 Hz
Australian and New ealand models
...................................................... AC 240 V, 50/60 Hz
Power consumption
European and K models .................................... 157 W
Australian and New ealand models .................. 156 W
Singapore, Malaysian, Hong Kong, and
Central and South American models ................ 152 W
All other models ................................................. 436 W
Power consumption in standby mode ............................ 1 W
Miscellaneous
Dimensions ...................... 420 (W) x 455 (D) x 125 (H) mm
Weight ........................................................................... .0 kg
Speaker system (S-HTD50/ S-HTD5)
(Front Speaker x 2, Surround Speaker x 2, Center Speaker
x 1, Subwoofer x 1)
