1997 Apr 10 6
Philips Semiconductors Product specification
CATV amplifier module BGY685AL
PACKAGE OUTLINE
Dimensions in mm.
(1) Screw 6-32 UNC-2A available on request.
(2) Leads gold plated.
Fig.2 SOT115J.
handbook, full pagewidth
1 7 8
20.8
max
4.2
M
∅ 0.25
9
0.51
0.38
(2)
(5.08)
2.54
UNC 6-32 (1)
25.4
12.7
27.2 max
3.8
max
8.8
min
9.2
max
8
13.8 max
0.25
2.54
2.4 max
44.8
max
38.1
4.15
3.85
MSA318 - 1
10.2
4.15
3.85
2 3 5
