5
NOTE: Depending upon the features on the lawn mower model you purchased, all the
parts shown may not be included with your mower.
For ease of assembly, aside of your work area, lay out all hardware in the groups shown.
Each step of the assembly instructions will identify the group needed for that step.
(1) Lower Handle
(1) Upper Handle
(4)
Wheels
(1) Discharge Guard
(Side Discharge models only)
(1) Control Bar
(1) Engine Zone
Control Cable
(1) Remote Throttle Control
(If Equipped)
(1) Grass Catcher Bag
(Rear Discharge mowers only)
(1) Grass Catcher Frame
(Rear Discharge mowers only)
(4) Wheel Height Adjusters
(If Equipped)
NOTE: Some model lawn mowers
already have the wheels
preassembled to the mower.
PARTS PACKED SEPARATELY IN CARTON
PARTS BAG CONTENTS NOT SHOWN ACTUAL SIZE
(1) Upstop
Bracket
(4) Hubcaps
(If Equipped)
Side Mount
Cable
Ties
Center Mount
One (1) only of the Starter
Rope Guides shown below:
